冠嘉系統科技(RWD)
- 亮度 (Typ.)：400nit（APL 25%，無玻璃）
- 透明度 (Typ.)：38%
- 邊框：7.9 mm (T/B/L), 121.7 mm (B)
- 介面：HDMI/DP/USB(2)/RS232C/RJ45/音訊/IR
※本網站所提供產品規格內容如有變更，恕不另行通知。實際請以LG官方最新公告資訊為主。
| 機型 | 55EW5G-A | |
|---|---|---|
| PANEL | ||
| Screen Size | 55" | |
| Panel Technology | OLED | |
| Native Resolution | 1,920 x 1,080 (FHD) | |
| Brightness | 150/400nit (APL 100%/25%, Without Glass) | |
| Contrast Ratio | 150,000 : 1 | |
| Dynamic CR | No | |
| Color gamut | BT709 120 % | |
| Viewing Angle (H x V) | 178 x 178 | |
| Color Depth | 10bit(R), 1.07Bilion colors | |
| Response Time | 1 ms (G to G) | |
| Surface Treatment (Haze) | Hard coating (2H) | |
| Operation Hours (Hours / Day) | 18 / 7 (Moving Content Only) | |
| Portrait / Landscape | Yes / Yes | |
| Transparency | 38% (SET) | |
| CONNECTIVITY | ||
| Input | HDMI (1, HDCP1.4), DP (1, HDCP1.3), RS232C IN, RJ45(LAN), IR IN (1, External IR Receiver), USB2.0 Type A(2) | |
| Output | DP Out, Audio Out, RS232C OUT (1, w/ IR out), RJ45(LAN) | |
| MECHANICAL SPECIFICATION | ||
| Bezel Color | Transparent | |
| Bezel Width | T/R/L/B : 7.9/7.9/7.9/121.7mm | |
| Weight (Head) | 11.6Kg (Head), 3.4Kg (Signage Box) | |
| Monitor Dimension (W x H x D) | 1225.5 x 810.1 x 4.9mm (Head) | |
| Monitor Dimensions with Stand (W × H × D) | No | |
| VESA™ Standard Mount Interface | No | |
| Protection Glass | Depth 3.0 mm , Tempered / Chemical Strengthening, Anti-Reflective, Shatter-Proof | |
| FEATURE | ||
| HW | Internal Memory (16GB), Temperature Sensor | |
| SW | webOS ver. (webOS4.0), Local Contents Scheduling, Group Manager, USB Plug & Play, Fail over, RS-232C Sync, Local Network Sync, Video Tag (4), Gapless Playback, Tile Mode Setting, Setting Data Cloning, SNMP, ISM Method, Auto Set ID, Status Mailing, Control Manager, Crestron Inside, PM mode, Wake on LAN, HDMI-CEC, SI Server Setting, Pro:Idiom | |
| ENVIRONMENT CONDITIONS | ||
| Operation Temperature | 0 °C to 40 °C | |
| Operation Humidity | 10 % to 80 % | |
| POWER | ||
| Power Supply | AC 100-240V~, 50/60Hz | |
| Power Type | Built-In Power | |
| POWER CONSUMPTION | ||
| Typ. / Max. | 250 W / 280 W | |
| BTU (British Thermal Unit) | 853.03 BTU/Hr(Typ.), 955.39 BTU/Hr(Max) | |
| SOUND | ||
| Speaker | No | |
